Specifications |
Technique |
|
Output specification |
4~20mA |
|
Output linear |
0.05% |
|
Comprehensive accuracy |
0.2% |
|
Output ripple |
≤5mVp-p |
|
AD sampling |
40SPS |
|
Input load |
1~4load cells |
|
Excitation voltage |
6VDC |
|
Output load |
≤500Ω |
|
Power supply |
15~26VDC |
|
Power waste |
≤0.2W |
|
Operation temp range |
-20~60℃ |
|
Weight approx. |
0.45kg |
|
Material |
Aluminum ally |
|
IP Class |
IP66 |
Características y aplicaciones
lUsando un conector impermeable especial
l Use el potenciómetro de múltiples vueltas con alta estabilidad para hacer compensación y ajuste
l Cubra con una junta de goma impermeable que podría ser impermeable y a prueba de polvo, adecuada para condiciones industriales duras
l Prevenga el daño del sensor por la inducción de rayos y la señal de sobretensión
l Utilice una caja de conexiones de entrada y una de salida
|
Specifications |
Technique |
|
Output specification |
4~20mA |
|
Output linear |
0.05% |
|
Comprehensive accuracy |
0.2% |
|
Output ripple |
≤5mVp-p |
|
AD sampling |
40SPS |
|
Input load |
1~4load cells |
|
Excitation voltage |
6VDC |
|
Output load |
≤500Ω |
|
Power supply |
15~26VDC |
|
Power waste |
≤0.2W |
|
Operation temp range |
-20~60℃ |
|
Weight approx. |
0.45kg |
|
Material |
Aluminum ally |
|
IP Class |
IP66 |
